TP-Link TL-SF1005LP 5-Port Desktop Switch with 4-Port PoE
$59.00
Skip to product information
TP-Link TL-SF1005LP 5-Port Desktop Switch with 4-Port PoE
$59.00
In stock, ships from Australia
- Free shipping over $300 Flat $20 under that
- Express 1 to 2 business days To most Australian addresses
- 30-day returns On unused gear
- 5-year warranty From the manufacturer, plus your Australian Consumer Law rights
Overview
Get your cameras online and powered up from one spot in the shed or office. It has four PoE ports with a 41W power budget and an extend mode for longer cable runs.
Key features
- Plug and play setup with no configuration required
- Extend Mode increases data and power transmitting range up to 250 m
- Priority Mode guarantees quality for sensitive applications on ports 1-2
- Fanless design for silent operation
- Physical security lock for hardware protection
Connectivity
- Network media 10BASE-T: UTP category 3, 4, 5 cable or EIA/TIA-568 100 ohm STP (maximum 100m)
- Network media 100BASE-TX: UTP category 5, 5e cable or EIA/TIA-568 100 ohm STP (maximum 100m)
- AUTO Negotiation and AUTO MDI/MDIX
- IEEE 802.3x flow control for full-duplex mode and backpressure for half-duplex mode
Certifications
- FCC, CE, RoHS
In the box
- TL-SF1005LP
- Power adapter
- Installation guide
Specifications
| General | |
|---|---|
| Brand | TP-LINK |
| SKU | TL-SF1005LP |
| Warranty | 5-year manufacturer warranty, plus your rights under Australian Consumer Law |
| Performance | |
| Interface | 5 x 10/100 Mbps RJ45 ports |
| Switching capacity | 1 Gbps |
| Packet forwarding rate | 0.744 Mpps |
| Mac address table | 2K |
| Jumbo frame | 2 KB |
| Transmission method | Store-And-Forward |
| PoE | |
| PoE ports | Ports 1-4 |
| Standard | IEEE 802.3af compliant |
| Total PoE power budget | 41 W |
| Power | |
| External power adapter | 53.5 V DC / 0.81 A |
| Max power consumption (no PD connected) | 1.9 W |
| Max power consumption (with 41 W PD connected) | 47 W |
| Physical specs | |
| Dimensions | 100 x 98 x 25 mm |
| Weight | 0.72 kg |
| Environment | |
| Operating temperature | 0-40 C |
| Storage temperature | -40-70 C |
| Operating humidity | 10-90% RH non-condensing |
| Storage humidity | 5-90% RH |
Specifications come from the manufacturer and can change between production runs.
