TP-Link TL-SF1009P 9-Port 10/100Mbps Switch with 8 PoE+ Ports
$68.50
Skip to product information
TP-Link TL-SF1009P 9-Port 10/100Mbps Switch with 8 PoE+ Ports
$68.50
In stock, ships from Australia
- Free shipping over $300 Flat $20 under that
- Express 1 to 2 business days To most Australian addresses
- 30-day returns On unused gear
- 5-year manufacturer warranty Plus your Australian Consumer Law rights
Overview
Power and connect your cameras from one spot with eight PoE+ ports. It handles up to 65W total and can push data and power up to 250 metres in Extend Mode.
Key features
- Plug and play operation with no configuration required
- Extend Mode increases data and power transmitting range up to 250 m
- Priority Mode guarantees quality for sensitive applications on ports 1-2
- Isolation Mode separates client traffic for higher security and performance
- Fanless design for silent operation
Connectivity
- Network media: UTP category 3, 4, 5, 5e and EIA/TIA-568 100Ω STP
- Auto negotiation and Auto MDI/MDIX
- Flow control: IEEE802.3x for full-duplex and backpressure for half-duplex
Specifications
| General | |
|---|---|
| Brand | TP-LINK |
| SKU | TL-SF1009P |
| Warranty | 5-year manufacturer warranty |
| Total ports | 9 |
| Performance | |
| Interface | 9× 10/100 Mbps RJ45 ports |
| Switching capacity | 1.8 Gbps |
| Packet forwarding rate | 1.3392 Mpps |
| Mac address table | 2K |
| Jumbo frame | 2 KB |
| Transmission method | Store-And-Forward |
| PoE | |
| PoE ports | 8× 10/100 Mbps 802.3af/at PoE+ ports |
| Standard | IEEE 802.3af/at compliant |
| Max power per port | 30 W |
| Total PoE power budget | 65 W |
| Power | |
| External power adapter | 53.5VDC / 1.31A |
| Max power consumption | 77.08 W (with 65 W PD connected) |
| Physical specs | |
| Dimensions | 171 × 98 × 27 mm |
| Physical security lock | Yes |
Specifications come from the manufacturer and can change between production runs.
Guides
| Resource | Type |
|---|---|
| TL-SF1009P datasheet | Datasheet |
| TL-SF1009P datasheet | Datasheet |
