TP-Link TL-SG1005LP 5-Port Gigabit Switch with 4 PoE+ Ports
$68.50
Skip to product information
TP-Link TL-SG1005LP 5-Port Gigabit Switch with 4 PoE+ Ports
$68.50
In stock, ships from Australia
- Free shipping over $300 Flat $20 under that
- Express 1 to 2 business days To most Australian addresses
- 30-day returns On unused gear
- 5-year manufacturer warranty Plus your Australian Consumer Law rights
Overview
Get your cameras and network gear connected with a simple plug and play setup. It features four PoE+ ports that provide up to 30W each, with a total power budget of 40W.
Key features
- Transfers data and power on one single cable via four PoE+ ports
- Plug and play setup with no configuration or installation required
- 802.1p/DSCP QoS enables smooth latency-sensitive traffic
- Fanless design for silent operation
Certifications
- FCC
- CE
- RoHS
In the box
- TL-SG1005LP
- Power adapter
- Installation guide
Specifications
| General | |
|---|---|
| Brand | TP-LINK |
| SKU | TL-SG1005LP |
| Warranty | 5-year manufacturer warranty |
| Total ports | 5 |
| Performance | |
| Interface | 5× 10/100/1000 Mbps RJ45 ports |
| Switching capacity | 10 Gbps |
| Packet forwarding rate | 7.44 Mpps |
| Mac address table | 2K |
| Jumbo frame | 16 KB |
| Transfer method | Store-And-Forward |
| PoE | |
| Standard | IEEE 802.3af/at compliant |
| PoE ports | Ports 1-4 |
| Max power per port | 30 W |
| Total PoE power budget | 40 W |
| Connectivity | |
| 10BASE-T | UTP category 3, 4, 5 cable or EIA/TIA-568 100Ω STP (maximum 100m) |
| 100BASE-TX | UTP category 5, 5e cable or EIA/TIA-568 100Ω STP (maximum 100m) |
| 1000BASE-T | UTP category 5, 5e, 6 or above cable or EIA/TIA-568 100Ω STP (maximum 100m) |
| Features | AUTO Negotiation, AUTO MDI/MDIX |
| Power | |
| External power adapter output | 53.5 VDC / 0.81 A |
| Max power consumption no PD connected | 4.12 W |
| Max power consumption with 40 W PD connected | 47.5 W |
| Specifications | |
| Dimensions | 99.8×98×25 mm |
| Operating temperature | 0-40 ℃ |
| Storage temperature | -40-70 ℃ |
| Operating humidity | 10-90% RH non-condensing |
Specifications come from the manufacturer and can change between production runs.
