TP-Link TL-SG1005P 5-Port Gigabit Switch with 4 PoE Ports
$78.73
Skip to product information
TP-Link TL-SG1005P 5-Port Gigabit Switch with 4 PoE Ports
$78.73
In stock, ships from Australia
- Free shipping over $300 Flat $20 under that
- Express 1 to 2 business days To most Australian addresses
- 30-day returns On unused gear
- 5-year manufacturer warranty Plus your Australian Consumer Law rights
Overview
Get your cameras and gear connected with one cable for both data and power. It features four PoE ports with a 56W total power supply and a fanless steel case.
Key features
- Transfers data and power on one single cable via four PoE ports
- Ensures smooth latency-sensitive traffic with 802.1p/DSCP QoS
- Requires no configuration or installation
- Silent operation with fanless design
Specifications
| General | |
|---|---|
| Brand | TP-LINK |
| SKU | TL-SG1005P |
| Warranty | 5-year manufacturer warranty |
| Total ports | 5 |
| Performance | |
| Interface | 5× 10/100/1000Mbps RJ45 Ports |
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.44 Mpps |
| Mac Address Table | 2K |
| Jumbo Frame | 16 KB |
| PoE | |
| Standard | 802.3 af/at compliant |
| PoE Ports | Ports 1-4 |
| Max power per port | 15.4 W |
| Total PoE power budget | 56 W |
| Connectivity | |
| Network Media 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m) or EIA/TIA-568 100 Ohm STP (maximum 100m) |
| Network Media 100BASE-TX | UTP category 5, 5e cable (maximum 100m) or EIA/TIA-568 100 Ohm STP (maximum 100m) |
| Network Media 1000BASE-T | UTP category 5, 5e, 6 or above cable (maximum 100m) or EIA/TIA-568 100 Ohm STP (maximum 100m) |
| Features | AUTO Negotiation, AUTO MDI/MDIX, IEEE 802.3x Flow Control, IGMP Snooping |
| Power | |
| External Power Adapter | 53.5 VDC / 1.31 A |
| Power Supply | 65 W |
| Max Power Consumption | 74.24 W (with 65 W PD connected) |
| Physical specs | |
| Dimensions | 99.8×98×25 mm |
| Weight | 0.76 kg |
Specifications come from the manufacturer and can change between production runs.
